RFID Button Laundry Tag

The RFID Laundry Button Tag is meticulously crafted for the demands of rugged and unforgiving work settings. HF/NFC and UHF button laundry tags represent compact RFID solutions designed for secure attachment to garments via buttons. While the market predominantly utilizes UHF laundry transponders, there is a growing requirement for NFC laundry tags compatible with mobile applications in certain scenarios.

The RFID laundry Button transponders aptly address these evolving needs and have found extensive application in the precise identification and tracking of industrial laundry and textile items across sectors such as hotels, healthcare facilities, and linen rentals.

Availability:



Inquiry

Product Description

MAIN FEATURES：

Item:	JYL-PLT15/16/18/20/23.5/24.5/30
Size:	- Diameter 18/24.5mm for UHF - Diameter 15/16/20/25.5/30mm for HF/NFC/LF
Color:	Black
Material:	PPS
Washing:	90℃(194οF), 60 minutes, more than 250 cycles
Drying	180℃(320οF), 10 minutes
Pressure	up to 20bar
Chemical Resistance	Typical chemicals used in laundry and dry-cleaning processes
IP Rating:	IP65 (condition: water pressure 45bar, 10h)
Character:	Flexible, Easy-to-install, Easy-touse, Waterproof, Damp-proof, Anti-Vibration,and High Temperature Resistance.
Operating Temperature:	-30°C ~ +200°C
Peak Temperature	160°C 3h, 220°C 30min

Picture	Dimension (mm)	RFID Chip	Material	Storage	Recycle Washing	Installation
	Φ30*3.0mm	LF/UHF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ25.5*2.7mm	LF/HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Sewing
	Φ25*2.6mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ24.5*3mm	HF/UHF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Sewing
	Φ23.5*2.3mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ20*2.6mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ18*2.8mm	UHF	PPS+Epoxy	-40C~+120C (-40F~+248F)	Over 200 times	Sewing
	Φ18*3mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ16*3mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch
	Φ15*3mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Sewing Two holes
	Φ15*2.2mm	HF	PPS	-40C~+120C (-40F~+248F)	Over 200 times	Pouch

RFID Laundry Button Variable Data

- Laser-Marked : LOGO | Numbering etc

- Re-programmable: UID / EPC Programming & Locked / Access Password

PPS laundry tag laser

Applications of RFID Laundry Button

Hotel linen management
Hospital linen tracking
Restaurant tablecloth and napkin control
Gym towel management
Spa and wellness center robes and linens
Uniforms and workwear tracking
Industrial laundry services
Linen Producer

JYL-Tech is a Pioneer in RFID Laundry Tags - JYL-Tech has established itself as a frontrunner in delivering cutting-edge RFID laundry transponders tailored for diverse applications like uniforms and workwear. Leveraging its profound expertise in RFID technology, JYL-Tech is dedicated to crafting inventive RFID washable tags that empower businesses to streamline their operations and bolster their bottom line.

JYL-PLT PPS RFID Laundry Tag Datasheet.pdf
